Nail Paint Filling Machine
Nail Paint Filling Machine Detail:
Model EGNF-01A Nail paint filling machine is an full automatic nail polish machine,push type, designed for the production of nail polish,gel polish,nail glue etc..
Nail paint
Indexing turn table with 39 bottlers holder, 10 working station
1 set of 60 L pressure tank,put on the ground
Automatic feeding empty bottles,fill balls ,loading brush,and cap loading and capping,auto discharging into output conveyor
1 set filling balls unit with automatic by cylinder,and fill 0 / 1 / 2 balls once
Needle valve filling system ,specially designed for nail polish,easy for color change and cleaning.
Piston filling system (Optional)
If material with more big glitter ,Suggest use piston filling system
Capping controlled by servo motor,capping torque adjustable.
Automatic discharge finished products into output conveyor
Nail Paint Filling Machine Capacity
30-35 bottles/min
Nail Paint Filling Machine Mold
POM pucks holders (customized according to different bottle shape and size)
| Model | EGNF-01A |
| Voltage | 220V 50Hz |
| Production type | Push type |
| Output capacity/hr | 1800-2100pcs |
| Control type | Air |
| No. Of nozzle | 1 |
| No. of working station | 39 |
| Vessel volume | 60L/set |
| Display | PLC |
| No. of operator | 0 |
| Power consumption | 2kw |
| Dimension | 1.5*1.8*1.6m |
| Weight | 450kgs |
| Air input | 4-6kgf |
| Optional | Pucks |
Auto feeding empty bottle system
Automatic filling wtih easy color change
Bottle sensor,no bottle no filling
Automatic filling stainless ball
Pressure tank put on the ground
Automatic loading brush
Auto inner cap loading system
Automatic inner cap capping
Auto outer cap loading system
Auto discharging into output conveyor
Auto capping head,capping torque adjustable
Electric components brand list
| Item | Brand | Remark |
| Touch screen | Mitsubishi | Japan |
| Switch | Schneider | Germany |
| Pneumatic component | SMC | China |
| Inverter | Panasonic | Japan |
| PLC | Mitsubishi | Japan |
| Relay | Omron | Japan |
| Servo motor | Panasonic | Japan |
| Conveyor&mixingmotor | Zhongda | Taiwan |
Product detail pictures:
